6W 48V Linear LED OSRAM chip Spotlight for Magnetic Track UGR17
The Linear LED Spotlight 6W is a modern and compact lighting solution designed to provide accent lighting without glare, thanks to its UGR<17 rating.
Made of aluminum and PC, this magnetic linear spotlight features an elegant black housing that integrates perfectly into any environment. It incorporates a high-performance OSRAM LED chip that offers a luminous flux of 600 lumens, ensuring excellent color reproduction with a CRI<90, reproducing vibrant and true-to-life colors.
The linear LED spotlight is designed to operate at 48V on magnetic tracks with a width of 27mm, and its click mounting system allows it to be easily placed on the track without the need for screws, fasteners, or tools.
- Power: 6W
- Luminous Flux: 600 lumens
- UGR Rating: <17
- CRI: <90
- Operating Voltage: 48V
- Dimensions: 112x22x42mm
Linear LED Spot 6W for 48V Magnetic Track UGR<17 Adjustable
The 6W linear LED spot for the 48V magnetic track offers UGR < 17 visual comfort and magnetically attaches freely to the track, without tools. Adjustable, compact design (112x22x42 mm), ideal for modular, precise lighting.
⚡ 6W🧨 48V👀 UGR < 17🔄 Orientable
| 6W Power | 48V Magnetic track | UGR < 17 Glare | Adjustable Spot |
The 6W linear LED spot is a module designed for the 48V surface magnetic track. It magnetically attaches freely along the whole length of the track, without tools, and repositions or aims as desired to direct the light exactly where you want.
With a UGR < 17 glare index, it ensures excellent visual comfort, ideal for offices, shops, showrooms and residential spaces. Its compact linear design (112x22x42 mm) integrates elegantly into the 48V modular system, to create modern, scalable accent lighting.
Why choose this product?
Attaches without tools, repositionable and adjustable.
Optimal visual comfort, low glare.
112x22x42 mm, modern accent lighting.
Technical specifications
| Product type | Linear LED spot for magnetic track |
|---|---|
| Power | 6W |
| System | 48V magnetic track |
| Glare | UGR < 17 |
| Orientation | Adjustable |
| Dimensions | 112x22x42 mm |
| Use | Indoor |
Advantages
- 48V magnetic track: attaches without tools.
- UGR < 17: visual comfort.
- 6W linear: compact, 112x22x42 mm.
- Adjustable: directable beam.
- Repositionable: modular lighting.
- Offices and shops: accent lighting.
Recommended applications
| 🚪 | Living rooms and kitchens — modular lighting. |
| 🏠 | Shops and showrooms — adjustable spots. |
| 🏛 | Offices — UGR<17 comfort. |
| 🌿 | Galleries — 48V system. |
Installation guide
| 1 | Switch off the power Cut the 48V track supply. |
| 2 | Place the spot Magnetically attach the spot to the track. |
| 3 | Aim it Aim the beam at the desired area. |
| 4 | Check Restore power and check the lighting. |
Frequently asked questions
On the 48V surface magnetic track, without tools.
Yes, its UGR < 17 index offers excellent visual comfort.
Yes, and freely repositionable on the track.
| ⚡ 6W 48V | 👀 UGR<17 Linear | 🧨 Magnetic Adjustable | 🔌 In stock Fast shipping |
Data sheet
- Power (W)
- 6
- Power source (V)
- 48V
- Color temperature CCT
- 3000K
4000K
- LED
- SMD2835
- LED chip brand
- OSRAM
- Dimmable
- Sí
- Luminous efficacy (Lm/W)
- 100
- Brightness (Lm)
- 600
- Color rendering index (Ra):
- ≥90
- Colour
- Black
- IP
- IP20
- Luminous angle
- 24º
- Measures (mm)
- 112x22x42mm
- Material
- Aluminum + PC
- Operating temperature
- -20ºC ~ +40ºC
- Energy efficiency 2021
- A+
- Energy efficiency 2023
- F
- Lifespan
- 30.000h
- Certification
- CE - RoHS
- Warranty
- 3 años
