60x60cm 52W UGR19 Slim PRO LED Panel LiFUD driver 4940Lm
The 60x60cm Slim PRO LED Panel offers a power of 52W and a brightness of 4940 lumens, with a high CRI>80. Equipped with high-brightness EPISTAR SMD2835 LED chips, it features an ultra-thin 10mm profileee, made of aluminum with a white frame and a low-glare microprismatic PMMA diffuser UGR<19. Includes a LIFUD external driver, flicker-free, of high quality and durability.
- Dimensions: 595x595x10mm
- Power: 52W
- Brightness: 4940 lumens
- LED Chip: EPISTAR SMD2835
- CRI: >80
- Diffuser: PMMA microprismatic UGR<19
- Profile: Ultra-thin, 10mm thick
- Material: Aluminum with white frame
- Driver: External LIFUD, flicker-free
- IP Rating: IP20
- Lifespan: 35000 hours
Slim PRO LED Panel 60x60 cm 52W UGR<19 LIFUD Driver 4940 lm
The 60x60 cm Slim PRO LED panel at 52W with an EPISTAR SMD2835 chip delivers 4940 lumens, CRI > 80. Ultra-thin 10 mm profile, microprismatic PMMA diffuser UGR < 19, external flicker-free LIFUD driver. 3-year warranty.
⚡ 52W💡 4940 lm👀 UGR < 19📏 10 mm
| 52W Power | 4940 lm Luminous flux | UGR < 19 Glare | 60x60 cm Format |
The 60x60 cm Slim PRO LED panel offers 52W of power and 4940 lumens of brightness, with a CRI > 80 colour-rendering index. Fitted with high-brightness EPISTAR SMD2835 LED chips, it has an ultra-thin 10 mm profile, made of aluminium with a white frame.
Its microprismatic PMMA diffuser with low glare UGR < 19 provides comfortable, even lighting, ideal for workspaces. It includes a high-quality external flicker-free LIFUD driver, with a power factor > 0.9. Dimensions 595x595x10 mm, IP20 protection, 35,000-hour lifespan and a 3-year warranty.
Why choose this product?
Microprismatic PMMA diffuser, comfortable lighting.
Elegant design, discreet integration, 4940 lm.
Flicker-free, power factor > 0.9, 3-year warranty.
Technical specifications
| Product type | 60x60 cm Slim PRO LED panel |
|---|---|
| Power | 52W |
| Luminous flux | 4940 lm |
| LED chip | EPISTAR SMD2835 |
| CRI | > 80 |
| Diffuser | Microprismatic PMMA (UGR < 19) |
| Profile | Ultra-thin, 10 mm |
| Dimensions | 595x595x10 mm |
| Material | Aluminium, white frame |
| Driver | External LIFUD, flicker-free (PF > 0.9) |
| Protection | IP20 |
| Lifespan | 35,000 hours |
| Warranty | 3 years |
Advantages
- UGR < 19: microprismatic PMMA diffuser.
- Ultra-thin 10 mm profile: discreet integration.
- 4940 lm, 52W: EPISTAR SMD2835 chip.
- LIFUD driver: flicker-free, PF > 0.9.
- CRI > 80: good colour rendering.
- 3-year warranty: 35,000-hour life.
Recommended applications
| 🚪 | Offices — comfortable UGR < 19 lighting. |
| 🏠 | Shops and hotels — even light. |
| 🏛 | Healthcare facilities — quality lighting. |
| 🌿 | Meeting rooms — 60x60 false ceilings. |
Installation guide
| 1 | Switch off the power Cut the supply before installation. |
| 2 | Wire the LIFUD driver Connect the external driver to the panel and the mains. |
| 3 | Install the panel Recess the panel in a 60x60 false ceiling or use a surface/suspension kit. |
| 4 | Check Restore power and check the lighting. |
Frequently asked questions
Yes, an external flicker-free LIFUD driver is included.
UGR < 19, thanks to the microprismatic PMMA diffuser.
3 years, with a 35,000-hour lifespan.
| ⚡ 52W 4940 lm | 👀 UGR < 19 CRI > 80 | 🔌 LIFUD Flicker-free | 🛡 Warranty 3 years |
Data sheet
- Power (W)
- 52
- Power source (V)
- 220-240V
- Color temperature CCT
- 4000K
- LED
- SMD2835
- LED chip brand
- EPISTAR
- Brightness (Lm)
- Color rendering index (Ra):
- ≥80
- IP
- IP20
- Luminous angle
- 120
- Power factor φ
- Measures (mm)
- 595x595x10mm.
- Material
- Aluminum + PMMA
- Driver
- Operating temperature
- -20ºC ~ +40ºC
- Energy efficiency 2021
- A+
- Energy efficiency 2023
- F
- Lifespan
- 35.000h
- Certification
- CE - RoHS
- Warranty
- 3 años
Specific References
- ean13
- 8435637220927
